02SH06A15D3F2 – Goulds eSH Pump – Three Phase, 15HP

$8,033.15

Product: Goulds 15HP eSH Series Three Phase Pump (230/3/60 and 460/3/60).
Model Number: 02SH06A15D3F2
Formerly: 5SH2M51A0, 5SH2M44A0
Impeller Diameter: 6.56″

SKU: 500152000 Category: Tags: , , , , , , , , , ,

Description

The e-SH 316 stainless steel (SS) end suction pump is a centrifugal pump featuring a corrosion resistant 316 SS impeller. It is specially designed to handle water, non-aggressive or moderately aggressive liquids in commercial, industrial and a diverse range of OEM applications.

The e-SH pump replaces the model SSH centrifugal pumps with better efficiency to help you reach your operational goals while maintaining proven performance. With standard back pull-out design, maintenance can be done without disconnecting the pump body from the piping.

Applications

  • Water circulation
  • Booster systems
  • Liquid transfer
  • HVAC pump replacements
  • General service pumping

PRODUCT FEATURES

    • AISI 316 stainless steel construction for reduced corrosion and improved strength and ductility
    • Back pull-out design allows easy access to impeller, bracket and motor to simplify maintenance
    • Interchangeable John Crane Type 21 mechanical seals increase long-term effectiveness
    • Replaceable wear rings to maximize wear life
    • NEMA premium efficient motors
    • Liquid temperatures up to 250°F
    • NSF/ANSI 61 Drinking Water System Components Standard (pumps assembled in factory)

Most commonly used for:

  • Optional Upsized Process Pump in Pro V Scroll / V Piston Series Systems 2×10 through 4×50 HP Chiller Capacity



Installation, Operation & Maintenance Instructions – Click Here

The Authorized Goulds Technical Brochure can be found at at the following link – Technical Brochure

You can find the Official Goulds Repair Manual at the following link – Repair Manual

Looking for additional information, you can find FAQ’s, Support, and Manuals at – MyChiller.com



Additional information

Weight 250 lbs
Dimensions 30 × 30 × 27 in
